Access to Data in Modbus PLCs from The Cloud via MQTT

EASY SMART CUSTOMIZABLE

The configurable Gateway ELCO35 enables communication between Modbus-RTU/ Modbus TCP Slave devices and MQTT broker/server). The communication is bidirectional, allowing for the reading of data from Modbus slave devices and writing to Modbus slave devices. The Gateway can send data read from Modbus to configurable topics on the MQTT broker (Publish) and receive configurable topics (Subscribe) to write this data into Modbus.

Why Choose Us?

AccessData from The Cloud

Read and write access to Modbus controllers, e.g. from Schneider Electric, Wago, Beckhoff, Phoenix Contact, Sensors, Actuators, E-Meters, etc.
Read and write access to Modbus controllers, e.g. from Schneider Electric, Wago, Beckhoff, Phoenix Contact, Sensors, Actuators, E-Meters, etc.
Easy local and global access to field data and routing through firewalls
Especially dedicated to retrofit upgrades, thus protecting former investments
No need for software updates, operating system patches and PC updates resulting in years of failure-free operation
Minimal PLC programming for register setup required
No dedicated PC required
Web-based interface for gateway configuration

ELCO35 IoT Gateway

ELCO35 IOT Gateway Specification

General:

Standard	EN61010-1 / EN61010-2 / CE, UL
Dimensions (W × H × D)	110mm x 100mm x 25mm
Weight (depending on variant)	max. 250 g (depending on variant)
Mounting	Top hat rail

Technical Data, Indoor use only:

Operating ambient temperature	-20 °C to + 60 °C
Power Supply	9V – 24V
Power consumption	max. 200 mA @ 24 VDC
Housing	Phoenix ICS
IP Protection Class	IP20
IP protection class control cabinet	min. IP44
Altitude	up to 1000 m AMSL
Transport and Storage	-20 °C - +70 °C
Humidity	10% - 95% non condensing
RTC	GoldCap for real-time functionality

DIN-Rail Sockets

Interfaces:

USB (Power for programming only)	1x USB-A
Ethernet	2x RJ45, 10/100Mbps
Serial	1x RS232+RTS/CTS isolated or 2x RS232 (RxD/TxD) isolated or 1x RS232+ 1x RS485 isolated
Modbus RTU	1x RS485
CAN	1x isolated CAN, second CAN available as TTL-signals on internal connector
Wireless	LTE optional (WLAN/Bluetooth on request)
Digital I/O	Via extension modules
Mass storage MMC/SD/SDIO	microSD Card Slot (max. 128 GB, class10)
User Control Elements	1x user button, 2x configurable user LED, 1x power status LED

Ethernet & Wi-Fi

Housing/Dimensions:

For easy implementation into industrial control system racks, ELCO35 Housing should come in a housing with integrated DIN-Rail sockets. Furthermore, the board should be equipped with connectors allowing for interconnection to commonly used industrial interfaces.

As an example, a Modular ICS packaging from Phoenix Contact was used.
